| מותג | Asus |
|---|
| Chipset | Intel® Z890 Chipset |
|---|
| Memory | 4 x DIMM slots, max. 192GB, DDR5 |
|---|
| יציאה גרפית | 1 x DisplayPort**1 x HDMI™ port*** 1 x Intel® Thunderbolt™ 4 port (USB Type-C®) supports DisplayPort and Thunderbolt™ video outputs****1 x USB 20Gbps port (USB Type-C®) supports DisplayPort video output****** |
|---|
| Expansion Slots | Intel® Core™ Ultra Processors(Series 2)*1 x PCIe 5.0 x16 slotIntel® Z890 Chipset1 x PCIe 4.0 x16 slot (supports x4 mode)1 x PCIe 4.0 x4 slot2 x PCIe 4.0 x1 slots |
|---|
| Storage Interface | Total Supports 4 x M.2 slots and 4 x SATA 6Gb/s ports* |
|---|
| Audio | Realtek ALC1220P 7.1 Surround Sound High Definition Audio CODEC*- Impedance sense for front and rear headphone outputs- Internal audio Amplifier to enhance the highest quality sound for headphone and speakers- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking- High quality 120 dB SNR stereo playback output and 113 dB SNR recording input (Line-in)- Supports up to 32-Bit/192 kHz playback*Audio Features- Audio Shielding- Rear optical S/PDIF out port- Premium audio capacitors- Dedicated audio PCB layers- Audio cover- Unique de-pop circuit |
|---|
| USB Ports | Rear USB (Total 8 ports)1 x Thunderbolt™ 4 port (1 x USB Type-C®)1 x USB 20Gbps port (1 x USB Type-C®)3 x USB 10Gbps ports (3 x Type-A)3 x USB 5Gbps ports (3 x Type-A)Front USB (Total 7 ports)1 x USB 20Gbps connector (supports USB Type-C®)1 x USB 5Gbps header supports 2 additional USB 5Gbps ports2 x USB 2.0 headers support 4 additional USB 2.0 portsUSB Type-C® power delivery output: max. 5V/3A |
|---|
| Operating System | Windows 11 (22H2 & later) |
|---|
| Form Factor | ATX Form Factor12 inch x 9.6 inch ( 30.5 cm x 24.4 cm ) |
|---|
